A basic understanding of the parts of a door can be valuable when you’re shopping for interior or exterior doors. Not only does knowing how a door is framed and built make it easier when it comes to ordering your doors, but this knowledge comes in handy when talking with your door installer or contractor.
Understanding the Door Frame
The door frame is what connects your door to the walls of your home. The frame consists of a head jamb or simply a head, which is the uppermost horizontal part of the frame. There are also two side jambs on each side of your door, and this is the part of the frame that’s connected to your wall with either nails or screws. The bottom of the door frame is known as the door sill.
There’s often a small gap between the door frame and the wall, so that gap is covered with a strip of trim wood known as casing. The threshold is the protective metal, wood, or stone cap that’s installed over the door sill. For exterior doors, the threshold is often sloped outwards to help keep rain and snow outside.
The Door Panel
The actual door itself is often referred to as the panel. The panel often has decorative rectangular panels inset into the door. The vertical pieces of the panel are referred to as stiles, and the horizontal pieces are called rails. Most panels have two stiles (one on each side) and at least three rails, including a top, middle, and bottom rail.
A vertical mullion is a narrow vertical piece that separates panels on decorative doors. The bore hole is a hole through the door panel where the door handle or lockset is installed. Some doors come with pre-drilled bore holes, although finding new doors without an existing bore hole is common.
Door Hardware Basics
The hinges are jointed metal fittings that connect the door panel to the frame. Most doors use three hinges, but larger, heavier doors typically require four hinges. The strike plate is a metal plate that’s fastened to the door jamb and has a hole or slot that receives the door latch when the door closes. The mortise plate is a long, flat metal plate that is mortised into the door panel, creating a flat, smooth surface. The door latch and deadbolt pass through the mortise plate to secure the door to a strike plate in the door frame.
A strike plate is a metal plate installed on the side jamb on the opposite side of the door panel from the hinges. The strike plate is lined up with the door handle and any deadbolts used, and this plate serves to strengthen the door frame. The handle or knob can be completely customized to match your decor and security needs. Door knobs are round mechanisms that usually turn to release the door latch to allow passage through the doorway. Decorative door knobs, also called dummy knobs, are non-turning knobs for use on closet doors that are secured with a magnetic latch. Passage handles are non-locking lever-style door handles used on interior doors.
A lockset is a door hardware set that includes the handle or knob, a matching strike plate, and a mortise plate.
Door Stiles and Rails Explained
The stile is the vertical framing member on each side of the door panel. Every door has a hinge stile where the hinges attach and a lock stile opposite it where the lockset hardware is installed. Rails run horizontally across the door and connect the two stiles. Most doors feature a top rail at the top, a bottom rail at the base, and intermediate rails in between. The lock rail sits at handle height and provides reinforcement where the lockset penetrates the door.
Weatherstripping and Door Sweeps
Proper weatherstripping prevents air leaks that waste energy and reduce home comfort. Compression weatherstripping is the most common type for door frames. This foam or rubber material compresses when the door closes to fill gaps. V-strip weatherstripping fits into channels in the door jamb and springs open to seal against the door edge.
Door sweeps attach to the bottom edge of the door to seal the gap between the door and threshold. Some sweeps include adjustable height mechanisms to compensate for carpet or uneven floors. Door shoes provide an alternative by wrapping around the bottom edge. Thompson Creek doors come equipped with Q-Lon weatherstripping and bulb-and-blade sweeps designed to eliminate drafts and reduce energy loss.
Door Threshold Types
The threshold serves as the transition between your doorway and floor while providing critical weather protection. Wood thresholds offer a traditional appearance and work well for interior applications. Metal thresholds, typically aluminum or bronze, provide excellent durability for high-traffic exterior entries.
Adjustable thresholds solve the problem of uneven floors or settling foundations. These thresholds feature adjustment screws that raise or lower sections independently. Some thresholds incorporate thermal breaks with insulating barriers that prevent cold transfer from outside to inside. Proper threshold installation requires precise leveling and secure fastening. The threshold must slope slightly outward to shed water away from the door.
Door Frame Components
The door frame provides structural support and proper alignment for smooth operation. Jamb depth refers to the thickness of the door frame from interior to exterior wall surface. Standard residential jamb depths include 4-9/16 inches for 2×4 wall construction and 6-9/16 inches for 2×6 walls.
Door frames use different materials depending on application. Wood frames remain popular for interior doors and some exterior applications. Steel frames offer superior strength and security for exterior doors without warping concerns. Fiberglass frames combine durability with thermal efficiency and resist rot, corrosion, and insect damage.
Professional installers use shims to ensure the frame sits perfectly level and plumb. Improper shimming causes doors to swing open or closed on their own, bind during operation, or fail to latch properly. Thompson Creek custom-manufactures door frames to your home’s exact specifications, ensuring perfect fit without field modifications.
Door Panel Construction Types
Modern doors feature various panel construction methods. Solid wood doors use lumber throughout their construction, providing maximum strength and traditional beauty. Hollow core doors feature two thin face panels bonded to a lightweight frame with honeycomb cardboard fill, working well for interior applications.
Solid core doors use engineered wood products or foam insulation between face panels, creating a dense door with good sound insulation. Steel doors with polyurethane foam cores deliver outstanding thermal efficiency for exterior applications. Thompson Creek steel doors feature foam cores surrounded by rot-resistant frames and thermal breaks to eliminate energy loss. Fiberglass doors replicate wood grain appearance while offering superior durability and energy efficiency.
Lockset Types and Hardware Installation
Door locksets provide security while allowing authorized access. Entry locksets feature a key cylinder on the exterior and a thumb turn lock on the interior. Grade 1 locksets offer the highest security rating. Privacy locksets include an interior push button lock without a key cylinder, working well for bathrooms and bedrooms. Passage locksets have no locking mechanism at all.
Handlesets combine a decorative exterior handle with a separate interior knob or lever and deadbolt. These create an elegant appearance for front entries while providing maximum security. Thompson Creek offers over a dozen elegant hardware styles to complement your door design. Proper hardware installation requires precise boring and mortising for reliable long-term operation.
Choosing the Right Door Components
Understanding door anatomy empowers you to make informed decisions about new door purchases, repairs, or upgrades. Each component plays a specific role in door function, appearance, and longevity. Quality components properly installed create doors that operate smoothly, seal effectively, and look beautiful for decades.
Thompson Creek custom-manufactures doors with precisely selected components for optimal performance in Mid-Atlantic conditions. Our doors feature polyurethane cores, Q-Lon weatherstripping, and bulb-and-blade sweeps specifically chosen to eliminate drafts and reduce energy loss. Professional installation by Thompson Creek’s factory-trained experts ensures each component functions as designed.
To learn more about door anatomy and the ways you can customize the parts of a door, contact our team of window and door experts at Thompson Creek. Our custom entry doors come with comprehensive warranties covering both products and installation for up to 50 years. Schedule your free in-home consultation to discuss your door needs with our experts.
